Anti Climb Fence Welded Wire Mesh 358 High Security Fence/Security 358 Clearvu Anti Climb Prison Fences
The product description -------------------------------------------------------------------------------------------
1.Introduction of anti-climb fence
High security 358 fence systerm is well known in the world as an anti-climb & anti-cut through
barrier, while providing the lowest level of visual impact to the surroundings.The panels are welded with high quality carbon iron wires. It is designed to give attractive, long lasting and secure perimeter protection for industrial and commercial properties, public utilities, and it is really suited for electronic alarm and detection systems - no blind spots for CCTV. It is also a good choice for Military, airports,secure units and prisons.Security 358 fence is the ultimate welded mesh system offering one of the most effective means of providing a high degree of physical perimeter protection where a discreet visual impact on the immediate environment is essential.
2. Productive process
Material: Manufactured from hard drawn wire and electro-resistance welded at every intersection Heavy Low Carbon Wire, Heavy Mild Steel Wire, Stainless Steel Wire.
3. specification:
Mesh pattern: 76.2mm (3") x 12.7mm (0.5") welded at each intersection
Horizontal wires: 4mm diameter at 12.7mm
centres Vertical wires: 4mm diameter at 76.2mm
centres Weld strength: 75% of the minimum tensile strength of the wire Tensile range 540-690 N/m²
Wire Dia.3.25mm,4mm
Openings: 12.7x50.8mm,12.7x76.2mm
Fence Height:1800,2000,2400,3000,4000,5200mm
Colours:
Standard colours are Green RAL6005 and Black RAL9005.Other colours are available on request.
Product display -------------------------------------------------------------------------------------------------------
a> Securi for 358 Hi-Security System
| Panels | Posts |
| Fence | Panel Size | section | O/A Length | Total number of fixings | |
| Height | Height/Width | | | Inters- 1 Clamp bar | Corners- 2 Clamp bars | |
| m | mm | | | | |
| | | | | | | |
| 2.0 | 2007 x 2515 | 60x60x2.5mm | 2700 | 7 | 14 | |
| 2.4 | 2400 x 2515 | 60x60x2.5mm | 3100 | 9 | 18 | |
| 3.0 | 2997 x 2515 | 80x80x2.5mm | 3800 | 11 | 22 | |
| 3.3 | 3302 x 2515 | 80x80x2.5mm | 4200 | 12 | 24 | |
| 3.6 | 3607 x 2515 | 100x60x3mm | 4500 | 13 | | |
| 3.6 | 3607 x 2515 | 100x100x3mm | 4500 | | 26 | |
| | | | | | | |
b> Securifor 358 Maximum Security System
| Panels | Posts |
| Fence | Panel Size | section | O/A Length | Total number of fixings |
| height | Height/Width | | | Inters- 1 Clamp bar | Corners- 2 Clamp bars |
| m | mm | | | | |
| 4.2 | 4204 x 2515 | 100x100x4mm | 5200 | 15 | 30 |
| 4.5 | 4496 x 2515 | 100x100x5mm | 5500 | 16 | 32 |
| 5.2 | 5207 x 2515 | 120x120x5mm | 6200 | 18 | 36 |
4. Application:
High security 358 fence is world renouned for its performance as an anti-climb & anti-cut through barrier, whilst providing the lowest level of visual impact to the surroundings. Designed to give attractive, long lasting and secure perimeter protection for retail,industrial and commercial properties, schools, public utilities and is ideally suited for electronic alarm and detection systems - no blind spots for CCTV. Military, airports, secure units and prisons.
5.Packing
1>There is rubber mat at the bottom of the pallet to avoid the pallet destroyed the panels
2>There is 4 metal corners to keep the pallet more strong.
3>There is metal plate under the plastic bandage to reduce the apressure of fence panels.
4>There is wooden plate at the top of fence panel which can protect the fence panels from
being crushed by other pallets.
The Company infomation -------------------------------------------------------------------------------------------
Koch Metal Net Co.,Ltd
Kochfence was established in 2013, is a professional manufacturer engaged in the research, development, production, sale and service of Defensive barrier, Welded Gabion Box, wire mesh fence ,chicken cage, 358 Railway Station Fence, Perforated tube.
In addition, we have obtained ISO EU CE certificates. Selling well in all cities and provinces around China, our products are also exported to clients in such countries and regions as Britain, France, Germany, USA,UK Kenya, Zambia, Philippines, Thailand, Korea, New Guinea, Greece, Mexico.
